Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure

Certification
China Jianglang Technology  Co. Ltd. certification
China Jianglang Technology  Co. Ltd. certification
I'm Online Chat Now

Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure

Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure
Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure

Large Image :  Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure

Product Details:
Place of Origin: China
Brand Name: RV
Certification: CE , ATEX ,ISO9001
Model Number: RVP-53377-T
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiate
Packaging Details: Carton / Woodencase/ Pallet
Delivery Time: 1-7working day
Payment Terms: L/C, T/T, Western Union, D/A, D/P, Paypal
Supply Ability: 10000 SET Month

Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure

Description
Product Name: Air Diaphragm Pump Fuel: Air Driven
Brand Name: RV Model Number: RVP-53377-T
Lift: 230 FT / 70meter Application: Oil Painting Ink
Material Of Diaphragm: NBR ( Bune-N ) Weight: 4.6kg
High Light:

Bune-N nitrile double diaphragm pump

,

nitrile diaphragm pump

,

nitrile double diaphragm pump materials 1/2"

1/2" Aluminum Low Flow Rate Low Pressure Air Driven Double Diaphragm Pump with NBR Diaphragm



Air Driven Double Diaphragm Pump Application:



RV air driven double diaphragm pumps use compressed air as power source, and it is the most advanced type of diaphragm pumps in market for the moment. It adopts three-way air pilot valve to achieve real no dead stop and faster reversing. It is widely applied in waste water treatment, chemical industry, petrochemical industry, painting, ceramics, environmental protection, printing and dyeing, etc. to deal with all kinds of corrosive, volatile, flammable, poisonous fluids with particles and high viscosity.



Outline Dimension Drawing

Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure 0



Max Discharge Pressure 100 psi ( 0.7Mpa, 7bar )
Max Capacity 15 gpm ( 57lpm )
Max Reciprocating Speed 400 cpm
Power Pnuematic
Max Permitted Grain 3/32 in ( 2.5mm )
Advantages: Explosion-proof
Air Inlet Size 1/4 in.npt (f)
Air Outlet Size 3/8 in.npt (f)
Fluid Inlet Size 3/4 in.
Fluid Outlet Size 3/4 in.
Net Weight 4.8kg






Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure 1





Packing & Shipping:



Bune-N Nitrile Double Diaphragm Pump Materials 1/2" Low Flow Low Pressure 2



Our service


* All of the enquiry will be replied within 24 working hours
* Professional air diaphragm pump producer, with design team.
* All of the goods are packed with standard export wooden case (non-fumigation)
* Fast after-service



FAQ

1. Q: Are you a factory or trading company?

A: We are a factory.



2. Q: What're your payments ?

A: T/T,Western Union,L/C etc.



3. Q: What about the package ?

A: Standard export plywood case or carton.



4. Q: How long is the warranty ?

A: According to international standards, products in standard operation is 1 year,except wearable parts.



5. Q: The use of air diaphragm pump have?

A: air diaphragm pump can suck the peanut, pickles, tomato slurry, red sausage, chocolate, hops and syrup etc.

Air diaphragm pump can suck the paint, pigment, glue and adhesive etc.

Air diaphragm pump can suck various glazed slurries of tile, porcelain, brick and chinaware etc.

Air diaphragm pump can suck various toxin and flammable or volatility liquid etc.

Air diaphragm pump can suck various strong acid, alkali and corrosive liquid etc.



6. Q: How air diaphragm pump quality and service?

A: Our air diaphragm pump have CE certificate, quality assured, can accept OEM, provide various personalized needs.
