Product Details:
|
| Product Name: | Air Diaphragm Pump | Air Inlet: | 1/2 " FNPT |
|---|---|---|---|
| Liquid Inlet: | 1 " | Liquid Discharge: | 1 " |
| Maximum Reciprocating Speed: | 276 Cpm | Connection Type: | FNPT / FBSP |
| Valve Seat: | Stainless Steel 304 | Diaphragm: | PTFE |
| High Light: | RV 1 inch air operated diaphragm pump 20 lpm,RV diaphragm pump 150 lpm,RV 1 inch stainless steel diaphragm pump |
||
1”Aluminum Casting Air Diaphragm Pump For Paint and Coating Transfer
What is a Air Diaphragm Pump? How it works in an industrial application?
An air diaphragm pump (AODD) is a type of positive displacement pump. It consists of two pumping chambers that are alternately filled and discharged by the movement of flexible diaphragms. Compressed air is alternately fed to, and vented from, air chambers on the opposite sides of the diaphragms to create the pumping action.
Air diaphragm pump (AODD) pumps are generally used for transfer applications and can handle a wide variety of feeds including sludges, slurries, abrasive and shear sensitive fluids. Air diaphragm pumps are robust, reliable and easy to maintain
Description:
1" air diaphragm pump
• The air diaphragm pump with convenient operating are widely used in various industries, such as petroleum, metallurgy, mining, coating material, printing, paper making, water treatment, automotive ect.
• It has two diaphragms, the compressed air come to the pump body to drive the pump in the constant action of sucking and releasing, so it can pump the liquids easily by this principle. Also it is very safe in dangerous environment since it has no electric motor.
Pneumatic Diaphragm Pump Application
|
APPLICATION FOR AIR DIAPHRAGM PUMP
|
|
| Chemical Factory |
Material handling or removable barrels material ( instead of |
| Pharmaceutical factory |
Material handling or removable barrels material ( instead of drum pumps ) |
| Pharmaceutical chemical factory |
Material handling or removable barrels material ( instead of drum pumps ) |
| Electroplating Machinery |
Pumping plating material or wastewater replacement. |
| Spinning factory |
Delivery dye for texitle production |
| Max Air Consumption |
45scfm(22.5L/s)
|
| Air Inlet Size | 1/2 in.npt(f) |
| Air Outlet Size | 3/4 in.npt(f) |
| Fluid Inlet Size | 1 in. |
| Fluid Outlet Size | 1 in. |
| Net Weight | Stainless Steel 15.7kg |
Packing & Shipping:
Our service
* All of the enquiry will be replied within 24 working hours
* Professional pump producer, with design team.
* All of the goods are packed with standard export wooden case (non-fumigation)
* Fast after-service
Company Introduction:
We have the following materials available, and our engineers will select the most suitable and economical material for you according to your specific working conditions.
Stainless steel is suitable for applications that require higher chemical and abrasion resistance.
Diaphragm material: PTFE, Santoprene, , Hytrel, Buna-N, etc.
Available inlet/outlet size: 1/2", 3/4", 1", 1-1/2", 2", 3"
FAQ
Q1. Can I have a sample order for air diaphragm pump?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 3-5 days for Sample preparing ,8-10 working days for mass production.
Q3. Do you have any MOQ limit for air diaphragm order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for air diaphragm pump?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to our air diaphragm pump.
