1/2 Air Diaphragm Pump For Slurry Hytrel Solar Submersible 7 Bar

1/2 Air Diaphragm Pump For Slurry Hytrel Solar Submersible 7 Bar
1/2 Air Diaphragm Pump For Slurry Hytrel Solar Submersible 7 Bar 1/2 Air Diaphragm Pump For Slurry Hytrel Solar Submersible 7 Bar

Large Image :  1/2 Air Diaphragm Pump For Slurry Hytrel Solar Submersible 7 Bar

Product Details:
Place of Origin: China
Brand Name: RV
Certification: CE , ATEX ,ISO9001
Model Number: RVP-52A55-T
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiate
Packaging Details: Carton / Woodencase/ Pallet
Delivery Time: 1-7working day
Payment Terms: L/C, T/T, Western Union, D/A, D/P, Paypal
Supply Ability: 10000 SET Month

1/2 Air Diaphragm Pump For Slurry Hytrel Solar Submersible 7 Bar

Description
Type: Pneumatic Diaphragm Pump Place Of Origin: Shanghai, China
Pressure: 7 Bar, Low Pressure Power: Pneumatic
OEM: Applicable Displacement Per Cycle (Liters): 0.15
Material Of Diaphragm: Hytrel Weight: 3.4kg
High Light:

1/2 air diaphragm pump for slurry

,

air diaphragm pump for slurry 7 bar

,

air diaphragm pump 1/2

1/2 Air Diaphragm Pump For Slurry Hytrel Solar Submersible 7 Bar



Pneumatic Diaphragm Pump Function Application:


The pneumatic diaphragm pumps use compressed air as power source, and it is the most advanced type of pneumatic diaphragm pumps in market for the moment. It adopts three-way air pilot valve to achieve real no dead stop and faster reversing. It is widely applied in waste water treatment, chemical industry, petrochemical industry, painting, ceramics, environmental protection, printing and dyeing, etc. to deal with all kinds of corrosive, volatile, flammable, poisonous fluids with particles and high viscosity.



Pneumatic Diaphragm Pump Spraying and Cleaning



Pnuematic Diaphragm pumps are perfect for spraying paint, cleaning roofs and spraying conveyers/bottles for anti-static. These pumps are suited for these types of applications due to their durability and the volume produced by each pump. The pneumatic diaphragm pump, combined with the power of an air compressor, allows cleaning chemicals, paints and other fluids to be dispensed at a constant rate.



Max Discharge Pressure 100 psi ( 0.7Mpa, 7bar )
Max Capacity 15 gpm ( 57lpm )
Max Reciprocating Speed 400 cpm
Power Pnuematic
Max Permitted Grain 3/32 in ( 2.5mm )
Advantages: Explosion-proof
Air Inlet Size 1/4 in.npt (f)
Air Outlet Size 3/8 in.npt (f)
Fluid Inlet Size 1/2 in.
Fluid Outlet Size 1/2 in.
Net Weight 3.4kg





Display


1/2 Air Diaphragm Pump For Slurry Hytrel Solar Submersible 7 Bar 0



Packing & Shipping:



1/2 Air Diaphragm Pump For Slurry Hytrel Solar Submersible 7 Bar 1


Company Information



Jianglang Technology Co.,Ltd headquartered in Jinshan District of Shanghai, with more than 120 employees and 2 manufacturing base. It has branch offices in Pudong District of Shanghai and Chengdu. It has been continuously granted as the “High-Tech Enterprise” and “Credit Company” every year.
We have department for independent design and innovation, we have skillful worker teams with strong ability for precision machining, we have tight cooperation with Shanghai universities.

we mainly produce Pneumatic Diaphragm Pump, Electric Diaphragm Pump, and Pump Systems Complete, Regulating Valve, Control Valve, Sequencing Valve, ect.


FAQ

1. Q: Are you a factory or trading company?

A: We are a factory.



2. Q: What're your payments ?

A: T/T,Western Union,L/C etc.



3. Q: What about the package ?

A: Standard export plywood case or carton.



4. Q: How long is the warranty ?

A: According to international standards, products in standard operation is 1 year,except wearable parts.



5. Q: The use of pneumatic operated diaphragm pump have?

A: pneumatic diaphragm pump can suck the peanut, pickles, tomato slurry, red sausage, chocolate, hops and syrup etc.

Pneumatic operated diaphragm pump can suck the paint, pigment, glue and adhesive etc.

Pneumatic operated diaphragm pump can suck various glazed slurries of tile, porcelain, brick and chinaware etc.

Pneumatic operated diaphragm pump can suck various toxin and flammable or volatility liquid etc.

Pneumatic operated diaphragm pump can suck various strong acid, alkali and corrosive liquid etc.



6. Q: How pneumatic diaphragm pump quality and service?

A: Our pneumatic operated diaphragm pump have CE certificate, quality assured, can accept OEM, provide various personalized needs.
