RV50 Stainless Steel Diaphragm Pump with 120 psi Max Pressure and 150 gpm Flow Rate

RV50 Stainless Steel Diaphragm Pump with 120 psi Max Pressure and 150 gpm Flow Rate
RV50 Stainless Steel Diaphragm Pump with 120 psi Max Pressure and 150 gpm Flow Rate RV50 Stainless Steel Diaphragm Pump with 120 psi Max Pressure and 150 gpm Flow Rate

Large Image :  RV50 Stainless Steel Diaphragm Pump with 120 psi Max Pressure and 150 gpm Flow Rate

Product Details:
Contact Now

RV50 Stainless Steel Diaphragm Pump with 120 psi Max Pressure and 150 gpm Flow Rate

Description
Max Working Pressure: 120psi(0.84Mpa ,8.4bar) Max Flow Rate: 150 Gpm(570 Lpm)
Max Reciprocating Speed: 145cpm Max Suction Height (Dry Suction): 5m
Max Permitted Grain: 6mm Max. Air Consumption: 140scfm(70L/s)
Air Inlet Size: 1/2 In.npt(f) Air Outlet Size: 1/2 In.npt(f)
Fluid Inlet Size: 2 In.npt(f) Fluid Outlet Size: 2 In.npt(f)
Weight: Aluminum Pump 29kg ; Stainless Steel 47kg; Ductile Iton 66kg
Highlight:

stainless steel diaphragm pump

,

RV50 diaphragm pump

,

diaphragm pump with warranty

RV50 Diaphragm Pump (Stainless Steel)
High-Flow Diaphragm Pump
Engineered for superior performance and reliability, this diaphragm pump offers exceptional flow rates and robust fluid handling capabilities, making it ideal for demanding industrial applications.
  • 2 in (50.8 mm) End-Porting
  • Larger Ports for Increased Flow
  • Up to 120 psi Fluid Pressure
  • Lube-Free Operation
Ideal for: Chemical processing, water treatment, general industrial fluid transfer, and more.
Contact Email: sales@rivervalve.com
Phone: 008615001858171
WhatsApp: 8615821368145
Technical Specifications
Parameter Value
Max Working Pressure 120psi (0.84 MPa, 8.4 bar)
Max Flow Rate 150 gpm (570 lpm)
Max Reciprocating Speed 145 cpm
Max Suction Height (Dry Suction) 5 m
Max Permitted Grain 6 mm
Max Air Consumption 140 scfm (70 L/s)
Air Inlet Size 1/2 in. npt (f)
Air Outlet Size 1/2 in. npt (f)
Fluid Inlet Size 2 in. npt (f)
Fluid Outlet Size 2 in. npt (f)
Weight Aluminum pump: 29kg; Stainless steel: 47kg; Ductile Iron: 66kg
