RV40 Full Stainless Steel Diaphragm Pump with 90 gpm Flow Rate and 100 psi Max Pressure

RV40 Full Stainless Steel Diaphragm Pump with 90 gpm Flow Rate and 100 psi Max Pressure
RV40 Full Stainless Steel Diaphragm Pump with 90 gpm Flow Rate and 100 psi Max Pressure

Large Image :  RV40 Full Stainless Steel Diaphragm Pump with 90 gpm Flow Rate and 100 psi Max Pressure

Product Details:
Contact Now

RV40 Full Stainless Steel Diaphragm Pump with 90 gpm Flow Rate and 100 psi Max Pressure

Description
Max Working Pressure: 100psi(0.7Mpa ,7bar) Max .flow Rate: 90 Gpm(340 Lpm)
Max Reciprocating Speed: 200cpm Max.Suction Height (Dry Sucking): 5m
Max Permitted Grain: 5mm Max Air Consumption: 125scfm(3.5m³/min)
Air Inlet Size: 1/2 In.npt(f) Air Outlet Size: 1/2 In.npt(f)
Fluid Inlet Size: 11/2 In.npt(f) Fluid Outlet Size: 11/2 In.npt(f)
Weight: Stainless Steel Pump 29.0kg
Aluminum Pump 16.0kg
Highlight:

stainless steel diaphragm pump

,

RV40 diaphragm pump with warranty

,

full stainless steel RV40 pump

RV40 Diaphragm Pump (Full Stainless Steel)
High-Flow Diaphragm Pump
Engineered for demanding industrial applications, this high-flow diaphragm pump offers exceptional performance and reliability. Its robust construction and advanced features ensure efficient fluid transfer in a wide range of scenarios.
Experience unparalleled efficiency with a compact, portable design that doesn't compromise on power. Ideal for industries requiring precise and high-volume fluid handling.
Key Features
  • High Flow Rate: 100 gpm (378 lpm) in a compact size
  • Durable Construction: Stainless steel center section for corrosive environments
  • Reliable Air Valve: Patented, high-reliability closed center air valve is online serviceable
  • Lube-Free Operation: Reduces maintenance and operational costs
  • Versatile Application: Suitable for a wide range of viscous and non-viscous fluids
Typical Applications
  • Moving fluids from slow moving to very flowable
  • Evacuating food process mixing kettles
  • Transferring ingredients from original containers to mixing tanks
  • Evacuating liquid concentrates from shipping tankers to holding vessels
  • Repackaging fluids from original containers to smaller receptacles
Product Specifications
Brand N/A
Origin N/A
Material Stainless Steel / Aluminum
Color N/A
FOB Unit piece
FOB Price 0
Technical Data
Parameter Value
Max Working Pressure 100psi (0.7Mpa, 7bar)
Max Flow Rate 90 gpm (340 lpm)
Max Reciprocating Speed 200cpm
Max Suction Height (Dry Sucking) 5m
Max Permitted Grain 5mm
Max Air Consumption 125scfm (3.5m³/min)
Air Inlet Size 1/2 in.npt(f)
Air Outlet Size 1/2 in.npt(f)
Fluid Inlet Size 1 1/2 in.npt(f)
Fluid Outlet Size 1 1/2 in.npt(f)
Weight Stainless steel pump 29.0kg
Aluminum pump 16.0kg
