Lab Vacuum Pump Oil-free Diaphragm Vacuum Pump
Technical Specifications
| Parameter |
Value |
| Max Working Pressure |
120 psi (0.84 MPa, 8.4 bar) |
| Max Flow Rate |
150 gpm (570 lpm) |
| Max Reciprocating Speed |
145 cpm |
| Air Inlet Size |
1/2 inch |
| Air Outlet Size |
3/4 inch |
| Fluid Inlet Size |
2 inch |
| Fluid Outlet Size |
2 inch |
Product Advantages
Packaging & Delivery
Company Profile
Jiangliang Technology Co., Ltd is headquartered in Shanyang Town, Jinshan District of Shanghai, with 2 production bases and 3 branches in mainland China. Shanghai Jianglang has been awarded as High-Tech Enterprise and Credit Company title in consecutive years.
We have strong capability of design, innovation, precision production and tight cooperation with Shanghai universities. Our main products include diaphragm pumps and control valves: Pneumatic Diaphragm Pump, Electric Diaphragm Pump, Piston Pump, Powder Pump, Sanitary Pump, Diaphragm Pump with Leakage Detector Controller, Pneumatic Diaphragm Regulating Valve, Control Valve, and Sequencing Valve.
Our pumps and valves have been granted more than 40 patents, including 10 invention patents. Shanghai Jianglang participated in setting norms and standards for technical specification for pneumatic diaphragm pumps in petrochemical industry according to national standard No.: SH/T 3191-2017. We hold necessary certificates including TS.A National Manufacturing License, CE, ATex, ISO9001, SGS and more.
We serve chemical industry, painting & coating industry, water treatment industry, petroleum industry, environmental protection industry, and food and pharmaceutical industry. Shanghai Jianglang has established long-term business relationships with famous enterprises such as BASF, Bayer, SAMSUNG. Our RV pneumatic diaphragm pump has been exported to more than 70 countries and regions.
Available Materials
- Wetted parts material: PP, PVDF, Acetal, Aluminum alloy, Ductile iron, stainless steel, etc.
- Diaphragm material: Teflon, Santoprene, Viton, Hytrel, Buna-N, etc.
Connection Options
- Available inlet/outlet sizes: 1/4", 3/8", 1/2", 3/4", 1", 1-1/2", 2", 3"
- Threaded connection: Plastic pumps from 1/4" to 1-1/2", and all metal pumps
- Flanged connection: Plastic pumps from 1/2" to 3"
Our Service
All enquiries will be replied within 24 working hours
Professional pump producer with dedicated design team
All goods packed with standard export wooden case (non-fumigation)
Fast after-sales service and technical support
Frequently Asked Questions
What is MOQ?
1 piece for regular product. Samples are available and sample cost can be deducted from future orders.
What's the payment method?
D/P, T/T, Western Union - please confirm with us with exact order.
What is the delivery time?
Depends on quantity. Generally 1-7 working days.
What about packaging?
Cartons with foam inside, wooden case, and pallet options available.
How are the products delivered to us?
By international express or sea freight.
How long is the warranty?
15 years warranty for air motor, 5 years for pump body.
Can products be made to different standards?
Yes, we can produce products according to custom requirements.
